CTS 96V 144V 100Ah 200Ah lifepo4 EV car battery pack lithium ion 96V 300Ah 400Ah for electric vehicle ev boat
Description
CTS 96V 300Ah LiFePO4 Battery for Electric Boat & Yacht
Reliable, Safe & Long-Life Power Solution for Electric Marine Propulsion
The CTS 96V 300Ah LiFePO4 marine battery is engineered for electric boats, yachts, and commercial electric vessels that require high voltage, high energy density, and maximum safety. Built with premium LiFePO4 cells and an intelligent BMS, this battery system delivers stable power output, long service life, and excellent performance in demanding marine environments.
◆ Built-in smart BMS monitor battery state
◆ Extremely safe, no explosion, no fire under collision
◆ Cooling and heating system optional
◆ Customized battery solutions base on yours requirements
◆ Excellent large current discharge performance
◆ Low self-discharge and good discharge performance at low temperatures
MODEL |
CTS96300 |
Cell Type - Chemistry |
Prismatic- LiFePO4 |
Rated Capacity |
304Ah |
Rated Voltage |
96V |
Energy |
29.18KWh |
Resistance |
30mΩ |
Self Discharge |
<3% per month |
PDU |
BMS, 400A relays, fuses, COM socket |
Dimensions (L x W x H) |
L1300*W500*H380mm
(Can make it smaller if you want)
|
Weight |
250Kg |
Enclosure Protection |
IP67 stainless steel case |
Discharge Cut-off Voltage |
75V |
Max Continuous Discharging Current |
300A |
Peak Discharge Current |
400A for 60 seconds |
Recommended Discharge Current |
300A |
Charging Limited Voltage |
109.5V |
Max Charging Current |
200A |
Recommended Charge Current |
100A |
Charge Temperature Range |
0~50℃ |
Discharge Temperature Range |
-20~60℃ |
Recommended Operating Temperature |
15~35℃ |
Available on request |
Size, C rate, Communication protocol |
Designed for Electric Boats & Yachts
This 96V high-voltage lithium battery system is optimized to work seamlessly with most 96V marine motor controllers and electric propulsion systems. It provides strong continuous discharge capability, ensuring smooth acceleration, stable cruising, and reliable power delivery on water.
Compared with traditional lead-acid batteries, the CTS LiFePO4 marine battery offers lighter weight, higher usable energy, faster charging, and significantly longer lifespan, making it an ideal upgrade for modern electric vessels.
Core Advantages
1. High-Safety LiFePO4 Chemistry
Excellent thermal stability and chemical safety
Low risk of thermal runaway
Ideal for enclosed marine installations and long-term use
2. Intelligent BMS Protection
Built-in smart Battery Management System (BMS) provides:
Over-charge & over-discharge protection
Over-current & short-circuit protection
High & low temperature protection
Cell balancing for consistent performance
This ensures maximum safety, reliability, and battery longevity under marine operating conditions.
3. High Energy Density & Extended Range
Up to 30kWh energy in a single battery pack
Fewer battery modules required
Extended cruising range per charge
4. Long Cycle Life & Low Total Cost of Ownership
Designed for deep-cycle use
Minimal capacity degradation over time
Lower maintenance and replacement costs compared to lead-acid systems
5. Marine-Grade Mechanical Design
Robust metal enclosure
Optional waterproof and anti-corrosion treatment
Designed to withstand vibration, humidity, and marine environments
