High Performance 614V 230Ah Lifepo4 Battery System for Electric Tractors Harvester Seeder
The CTS 614.4V 230Ah LiFePO₄ battery system delivers strong and stable power for electric tractors operating under heavy-duty farm conditions. With a modular structure and automotive-grade cells, it offers high torque output, long working hours, and excellent energy efficiency. Its built-in BMS ensures safe operation and intelligent monitoring during continuous field use.
Description
High Performance 614V 230Ah Lifepo4 Battery System for Electric Tractors Harvester Seeder
The CTS 614.4V 230Ah LiFePO₄ battery system delivers strong and stable power for electric tractors operating under heavy-duty farm conditions. With a modular structure and automotive-grade cells, it offers high torque output, long working hours, and excellent energy efficiency. Its built-in BMS ensures safe operation and intelligent monitoring during continuous field use.
╣PRODUCT DESCRIPTION
Rated voltage: 614.4V / Capacity: 230Ah
Total energy: 141.3 kWh
Rated power: 70kW (280kW peak, 10s)
LiFePO₄ chemistry, >4000 cycle life
Optional air or liquid cooling
High IP rating for field dust and moisture protection
Intelligent Battery Management System with CAN/RS485 communication
Total energy: 141.3 kWh
Rated power: 70kW (280kW peak, 10s)
LiFePO₄ chemistry, >4000 cycle life
Optional air or liquid cooling
High IP rating for field dust and moisture protection
Intelligent Battery Management System with CAN/RS485 communication
Rated Volt |
Rated Capacity |
Total Energy |
Working Volt |
Disharge Power @ 25℃ |
||||||
1 |
307.2V |
105Ah |
32.36kWh |
240V-345V |
16kW rated 32kW max |
|||||
2 |
460.8V |
206Ah |
94.9kWh |
360V-525V |
50kW rated 100kW max |
|||||
3 |
614.4V |
105Ah |
64.5kWh |
480V-700V |
32kW rated 64kW max |
|||||
4 |
614.4V |
206Ah |
126.4kWh |
480V-700V |
60kW rated 120kW max |
|||||
5 |
614.4V |
412Ah |
252.8kWh |
480V-700V |
120kW rated 210kW max |
|||||
6 |
768V |
206Ah |
158.2kWh |
600V-876V |
75kW rated 155kW max |
|||||
╣PRODUCT ADVANTAGES
Standardized Lithium Battery Modules
CTS standardized LiFePO₄ battery modules are designed for flexible system expansion, supporting multiple configurations from 15kWh for small electric tractors to 200kWh for large combine harvesters. This modular design ensures high compatibility across various agricultural machinery and allows easy capacity scaling based on power demand.
IP67-Rated Protection for Harsh Farm Environments
Each lithium battery pack features a sealed IP67-rated enclosure, offering complete dustproof and waterproof protection. The robust design withstands mud, vibration, and temperature extremes ranging from -30°C to 60°C, making it reliable for outdoor agricultural operations all year round.
High Power Output and Fast Response Performance
Engineered for efficiency, CTS batteries support continuous discharge rates above 3C, with power-oriented models reaching up to 5C. This enables rapid torque response and stable high-power output for demanding equipment such as electric tractors, harvesters, and seeders.
Lightweight Structure for Reduced Mechanical Load
The lithium battery system weighs about one-third of traditional lead-acid batteries, significantly reducing total machine weight. This design minimizes soil compaction and enhances energy efficiency — especially suitable for compact orchard tractors, agricultural robots, and spray drones where lightweight and balance are critical.
CTS standardized LiFePO₄ battery modules are designed for flexible system expansion, supporting multiple configurations from 15kWh for small electric tractors to 200kWh for large combine harvesters. This modular design ensures high compatibility across various agricultural machinery and allows easy capacity scaling based on power demand.
IP67-Rated Protection for Harsh Farm Environments
Each lithium battery pack features a sealed IP67-rated enclosure, offering complete dustproof and waterproof protection. The robust design withstands mud, vibration, and temperature extremes ranging from -30°C to 60°C, making it reliable for outdoor agricultural operations all year round.
High Power Output and Fast Response Performance
Engineered for efficiency, CTS batteries support continuous discharge rates above 3C, with power-oriented models reaching up to 5C. This enables rapid torque response and stable high-power output for demanding equipment such as electric tractors, harvesters, and seeders.
Lightweight Structure for Reduced Mechanical Load
The lithium battery system weighs about one-third of traditional lead-acid batteries, significantly reducing total machine weight. This design minimizes soil compaction and enhances energy efficiency — especially suitable for compact orchard tractors, agricultural robots, and spray drones where lightweight and balance are critical.
╣APPLICATIONS
CTS batttery can widely used in Electric Tractor, Electric Micro Tiller, Electric Rotary Tiller, Electric Seeder, Electric Weeder, Electric Harvester, Electric Lawn Mower, Electric Agricultural Transport Vehicle etc..
Advantages of Electric Agricultural Machinery
Environmental Protection
Zero emissions,Reduces reliance on fossil fuels.
Low Noise
Suitable for greenhouses and farms near urban areas.
Energy Efficiency
Lower operational costs compared to fuel-powered machinery.
Advantages of Electric Agricultural Machinery
Environmental Protection
Zero emissions,Reduces reliance on fossil fuels.
Low Noise
Suitable for greenhouses and farms near urban areas.
Energy Efficiency
Lower operational costs compared to fuel-powered machinery.
╣WHY CHOOSE US ?
Over 14 years of lithium battery manufacturing experience
Focus on customized LiFePO₄ power systems for mobility and industry
Modular & scalable design adaptable to diverse applications
Certified quality: ISO, CE, UN38.3, MSDS, etc.
Global customers in 20+ countries and regions.
Focus on customized LiFePO₄ power systems for mobility and industry
Modular & scalable design adaptable to diverse applications
Certified quality: ISO, CE, UN38.3, MSDS, etc.
Global customers in 20+ countries and regions.
╣OUR FACTORY
Hunan CTS Technology Co., Ltd. is a professional manufacturer and solution provider specializing in customized lithium battery systems for industrial and transportation applications.
With over 14 years of experience in lithium battery design, R&D, and production, CTS has delivered reliable power solutions for electric trucks, buses, boats, agricultural machinery, and energy storage systems worldwide.
Our factory is located in Changsha, Hunan, equipped with advanced automated production lines and strict quality control systems. CTS focuses on LiFePO₄ battery technology, known for its high safety, long cycle life, and environmental sustainability.
Guided by the philosophy of “Safety, Efficiency, and Innovation,” CTS continues to empower global electrification through smart, high-performance lithium energy systems.
With over 14 years of experience in lithium battery design, R&D, and production, CTS has delivered reliable power solutions for electric trucks, buses, boats, agricultural machinery, and energy storage systems worldwide.
Our factory is located in Changsha, Hunan, equipped with advanced automated production lines and strict quality control systems. CTS focuses on LiFePO₄ battery technology, known for its high safety, long cycle life, and environmental sustainability.
We provide complete system integration services, including battery modules, BMS (Battery Management System), PDU (Power Distribution Unit), and thermal management systems, ensuring our clients receive turnkey power solutions tailored to their specific applications.
Guided by the philosophy of “Safety, Efficiency, and Innovation,” CTS continues to empower global electrification through smart, high-performance lithium energy systems.
